This revolves around the use of open standards (Open BIM).
Frilo shark software#
With intelligent and innovative software solutions, the Nemetschek Group increases quality in the building process and improves the digital workflow of all those involved in the building process.
As the sole corporate group worldwide, Nemetschek covers the entire life cycle of building and infrastructure projects with its software solutions and guides its customers into the future of digitalization. The Nemetschek Group is a pioneer for digital transformation in the AEC industry. In 1999, FRILO joined the Nemetschek Group as an independent brand. In doing so, FRILO follows the practical requirements of the engineer's everyday life and, in addition, provides highly qualified customer service. With more than 40 years of experience and about 100 static software solutions FRILO is one of the leading providers of innovative calculation programs for structural analysis and structural design.įRILO software solutions are characterized by their ease of use, fast results and continuous adaptation to current standards. The product database for approval masonry was expanded to include the product range from Kellerer ZMK brick systems from Ziegelsysteme Michael Kellerer GmbH & Co. KG can now be carried out according to the general method. In the Reinforced Concrete Column B5+ program, the design for the high-strength reinforcing steel SAS 670 from Stahlwerk Annahütte Max Aicher GmbH & Co. For Great Britain, the anchor strips of RFA-Tech Ltd. KG in the Punching Shear Analysis B6+ program. In addition to other punching shear reinforcements, structural engineers in Germany can now also choose Lattice Girders FDB from Filigran Trägerersysteme GmbH & Co. Punching Shear Analysis B6+ and Reinforced Concrete Column B5+ expanded with partner materials As a new program, the Bedded Beam BEB+ was also connected to the Building Model. In the basic building programs and Bunching B6+, only certain data from the data transfer can be transferred from GEO. When the calculation program for the respective component is started again, the linked position is suggested to the user. In the Building Model GEO, the link to the component position is retained when it is transferred to the component calculation programs now. In addition, the entry of area loads is now possible via an additional option. In the new 2020-2 version, the Framework RSX program was supplemented with the material reinforced concrete.
The program measures beams with composite cross sections and arbitrary loads.Įxtended functions for Framework RSX and Building Model GEO The solution Mechanically Jointed Beams HNV+ is also completely new in the product portfolio. Structural engineers can select the individual roof variants using an assistant,” explains Peter Fritz, Head of Product Management at FRILO.
Frilo shark plus#
“Roof+ replaces the previous roof solutions based on the new FRILO plus surface.
This enables the insertion of images and tables in the output as well as convenient formatting of the comments.įor an easier use, FRILO has combined its solutions Continuous Rafter D9, Purlin and Rafter Roof D11 as well as Collar Beam Roof D12 in one program. With the new Release 2020-2 all FRILO solutions of the PLUS program generation have implemented a remark editor now. PLUS programs expanded with remark editor In addition, all foundation programs now include the new Eurocode ÖNORM B : 2019. For the dimensioning and construction of steel structures, the new Eurocode ÖNORM B : 2017-11 was implemented in the current release. In addition, other programs have been expanded to include useful functions and partner products.įRILO Software GmbH continuously adapts its structural solutions to the currently applicable standards. In addition to the new Eurocodes for Austria, the provider of innovative solutions for statics and structural design has also implemented a new program for the calculation of roofs in its current Release 2020-2.
Frilo shark download#
Stuttgart, – As of today, structural engineers have been able to download the latest version of the FRILO structural analysis software. Release 2020-2 with new Eurocodes for Austria and program extensions
